Scanstrut SC-CW-11F ROKK Wireless – Nano 10W Waterproof Wireless Compact Phone Charging Mount 12V/24V

Description

The Scanstrut SC-CW-11F ROKK Wireless Nano is a compact 10W waterproof wireless charging mount designed for outdoor and marine environments. Built to Qi-certified standards, it provides fast, safe, cable-free charging for all compatible smartphones – even through most non-metallic waterproof cases.

With an IPX6 waterproof, fully sealed construction, the Nano is engineered from UV-stabilised, marine-grade materials, ensuring durability against sun, saltwater, and washdowns. Its side clamping jaws securely grip your phone in place, while the compact footprint makes it perfect for installations where space is limited.

The latest upgraded 10W charging technology delivers speeds up to 60% faster, designed to keep up with modern power-hungry devices and apps. With features like foreign object detection, thermal cut-off, and vibration/impact-tested ruggedness, the Nano ensures safe and reliable charging in all conditions.

Installation is simple with a flat surface mount using four screws and included template. For the best grip performance, vertical mounting is recommended.

Key Features

• 10W fast wireless charging – up to 60% faster
• Compact design – perfect for space-limited installs
• IPX6 waterproof, fully sealed construction
• Qi-certified – universal compatibility
• Strong outdoor-ready side clamping jaws
• Single-handed phone docking
• UV-stabilised, marine-grade materials
• Tested against vibration, impact, saltwater & sun exposure

What’s Included

• 1 × Scanstrut SC-CW-11F ROKK Wireless Nano 10W Charging Mount
• Mounting hardware
• Installation guide and template

Applications

• Boat consoles & cockpits
• RVs & campervans
• ATVs & outdoor vehicles
• Space-limited dashboards & equipment panels

Click on the Details and Specification tabs for more information.

Specifications

Specifications:

Electrical:

• Input Voltage: 10–30V DC (12/24V systems)
• Max Input Current: 2A
• Output Power: 10W (9V, 1.1A)
• Standby Power Draw: <0.2W
• Certifications: Qi, CE, UKCA, FCC, ROHS, C-Tick, UN ECE R10, IC, PSE

Mechanical:

• IPX6 waterproof housing
• Compact, rugged design for tight spaces
• UV stabilised, marine-grade build
• Side clamping jaws for secure phone grip

Installation

Please follow the installation instructions in the Documents tab.

Documents and links

The following documents are available to download:

Installation instructions for the SC-CW-11F

Technical drawing of the SC-CW-11F
